Operation
16 3A8429A
10. Turn ON/OFF switch to OFF position.
Power button is not illuminated when
OFF.
11. Inspect for leaks. If leaks occur, per-
form Pressure Relief Procedure, page
13, then tighten all fittings. If there are
no leaks continue with the next step.
Fill Pump
1. Move suction tube to paint pail and
submerge suction tube in paint. When
spraying oil-based or flammable
materials, follow Grounding
Instructions, page 9.
2. Press ON/OFF switch to ON position.
Button is illuminated when power is ON.
3. Wait to see paint coming out of the
drain tube.
4. Press ON/OFF switch to OFF position.
Button is illuminated when power is
OFF.
NOTE: Some fluids may prime faster if
the ON/OFF switch is momentarily
turned off so the pump can slow and
stop. Turn ON/OFF switch on and off
several times if necessary.
High-pressure spray is able to inject toxins
into the body and cause serious bodily
injury. Do not stop leaks with hand or rag.
