Appendix E - System Events
100 313997ZAA
Appendix E - System Events
Event Code and
String Triggers
REL00: System Pow
ered On
The System was powered on.
REM00: System Pow
ered Off
The System was powered off.
REB00: Stop Button
Pressed
The Red stop button was pressed on
the Advanced Display Module.
RECH0: Learn Mode
Executed
A learn mode calibration was suc
cessfully completed.
RENN0: Automatic
Cal. Performed
The system was successfully charac
terized with the Automatic calibration.
RECA1: Red Material
SG Modified
The Red materials specific gravity
was modified.
RECB2: Blue Material
SG Modified
The Blue materials specific gravity
was modified.
RENC1: Cal. Point 1
Weight Entered
A value for the first point in the three
point calibration was entered.
RENC2: Cal. Point 2
Weight Entered
A value for the second point in the
three point calibration was entered.
RENC4: Cal. Point 1
Weight Erased
The running average for point one of
the three point calibration was erased.
RENC5: Cal. Point 2
Weight Erased
The running average for point two of
the three point calibration was erased.
REND0: Ratio Check
Dispense
A ratio check shot was dispensed
from the ratio check calibration
screen.
REA00: Disp.
Occurred (Shot #)
A dispense has occurred of the given
shot number.
REH00: Gel Timer
Dispense
The gel timer expired and the system
automatically took the gel shot.
RER01: Shot Count
Reset
A counter from the shot counters
maintenance page was erased
RER02: Seq. Posi
tion Count Reset
A counter from the sequence counters
maintenance page was erased
RERA1: Red Material
Volume Reset
The resettable totalizer for the Red
material volume was reset to zero.
RERB1: Blue Material
Volume Reset
The resettable totalizer for the Blue
material volume was reset to zero.
RERA2: Red Material
Weight Reset
The resettable totalizer for the Red
material weight was reset to zero.
RERB2: Blue Material
Weight Reset
The resettable totalizer for the Blue
material weight was reset to zero.
RERA3: Red Cycle
Count Reset
The resettable cycle counter for the
Red pump was reset to zero.
RERB3: Blue Cycle
Count Reset
The resettable cycle counter for the
Blue pump was reset to zero.
REQU1: Settings
Downloaded
The system settings were success
fully transferred from the ADM to a
USB drive.
REQU2: Settings
Uploaded
The system settings file was success
fully transferred from the USB drive to
the ADM.
REQU3: Language
Downloaded
The custom language file was suc
cessfully transferred from the ADM to
a USB drive.
REQU4: Language
Uploaded
The custom language file was suc
cessfully transferred from the USB
drive to the ADM.
REQU5: Logs Down
loaded
The Error/Event and Shot data logs
were successfully transferred from the
ADM to a USB drive.
REAR0: Night Mode
Recirc On
While in night mode the system has
automatically entered a low recircula
tion mode and attempted to turn on all
enabled conditioning zones.
REBR0: Night Mode
Recirc Off
While in night mode the system has
automatically stopped the low recircu
lation mode and turned off all condi
tioning zones.
