Appendix B - ADM Setup Screens Overview
68 313997ZAA
Appendix B - ADM Setup Screens Overview
The ADM will start in the Run screens at the “Home”
screen. From the Run screens, press to access
the Setup screens. If the Setup screens password is
turned on, use the ADM keypad to enter the password
then press .
From the Setup screens, press to access the Run
screens. For Run screens information, see Appendix C
- ADM Run Screens Overview on page 82. F
IG. 22
shows the flow of the Setup screens.
FIG. 22: Setup Screens Navigation Diagram
Calibration
Maintenance
Shot #1
Shot #2
Shot #...
Sequences #1
Sequences #2
Sequences #...
Advanced #1
Advanced #2
Advanced #...
System #1
System #2
System #3
Supply
Conditioning #1
Conditioning #2
Conditioning #3
