Graco HFR - Motor Control Module (MCM) Identification

Component Identification
28 313997ZAA
Motor Control Module (MCM)
For MCM location, see reference MA in FIG. 2 on
page 25. When installed, the end of the MCM with the
power input connection (12) faces down and the end
with the access cover (A) faces up.
The Motor Control Module uses an 8-position selector
switch to set the system maximum working pressure.
NOTICE
If the Motor Control Module is replaced, the selec
tor switch must be set prior to initial startup of the
Motor Control Module or damage may occur. See
HFR Repair manual for details, see Related Man
uals on page 3.
FIG. 4: MCM Component Identification
A
r_257396_3b9905_01b
r_257396_3b9905_03b
C
12
B
13
1A
11
1B
5
7
6
8
9
10
2
3
