PROBLEM
CAUSE SOLUTION
Displacement pump output low on
downstroke or both strokes
Pump inlet screen clogged Clean screen.
Pressure setting too low Increase pressure. See Startup,
Step 14, page 14.
Dirty outlet filter , tip filter or tip Clean filters and/or tips.
Piston packings worn or damaged Replace packings. See page 26.
Intake valve ball check not seating
properly
Clean and service intake valve. See page 26.
Engine RPM too low Increase throttle setting. See Startup,
Steps 5b and 14, page 14.
Clutch worn or damaged Replace clutch. See page 34.
Partially clogged suction tube assembly Remove and clean suction tube. During normal
flushing remove and clean the suction tube as-
sembly
separately to prevent further clogging.
Large pressure drop in hose Use larger diameter hose.
Paint leaks into wet–cup Loose wet–cup T ighten wet–cup just enough to stop leakage.
Throat packings worn or damaged Replace packings. See page 26.
Displacement rod worn or damaged Replace displacement rod. See page 26.
Spitting from gun Air in fluid pump or hose Check for loose connections at pump intake and
tighten. Them prime the pump.
See Startup , page 14.
T ip partially clogged Clear tip clog. See page 16.
Fluid supply is low or empty Refill and prime the pump. See Startup , page 14.
Check fluid supply often to prevent running the
pump dry.
Dried paint particles from a poorly cleaned
suction tube assembly
Remove and clean suction tube. During normal
flushing remove and clean the suction tube as-
sembly
separately to prevent further clogging.
