Graco Magnum True Airless Project Painter Plus User Manual

Know Your Sprayer
10 3A5431B EN
Know Your Sprayer
X5 and LTS15 Stand Models
Power - ON/OFF Switch
Pressure Control Knob
Prime/Spray Valve
Spray Tip
E PushPrime™ Button
F Suction Tube
G Drain Tube (with diffuser)
H Airless Spray Gun
J Spray Tip Guard
K Gun Trigger Lock
LGun Fitting
M Gun Filter (inside handle)
NPump
OInlet Valve
P Outlet Valve (airless hose connection)
Q Airless Hose
T Inlet Screen
U Power Cord
W Suction Tube Drip Cup
Model/Serial Tag (Not shown, located
on bottom of unit.)
See Quick Reference, page 30 for more
information.

Graco Magnum True Airless Project Painter Plus Specifications

General

Brand	Graco
Model	Magnum True Airless Project Painter Plus
Category	Paint Sprayer
Language	English
