Know Your Sprayer
3A5431B EN 9
Know Your Sprayer
Project Painter Plus
Power - ON/OFF Switch
Pressure Control Knob
Prime/Spray Valve
Spray Tip
F Suction Tube
G Drain Tube (with diffuser)
H Airless Spray Gun
J Spray Tip Guard
K Gun Trigger Lock
LGun Fitting
M Gun Filter (inside handle)
NPump
OInlet Valve
P Outlet Valve (airless hose connection)
Q Airless Hose
T Inlet Screen
U Power Cord
W Suction Tube Drip Cup
X Gun Holder
Y Tip Holder
Model/Serial Tag (Not Shown, located
on bottom of unit)
See Quick Reference, page 30 for more
information.
