Know Your Sprayer
3A5431B EN 11
Know Your Sprayer
X7 and LTS17 Cart Models
Power - ON/OFF Switch
Pressure Control Knob
Prime/Spray Valve
Spray Tip
E PushPrime™ Button
F Suction Tube
G Drain Tube (with diffuser)
H Airless Spray Gun
J Spray Tip Guard
K Gun Trigger Lock
LGun Fitting
M Gun Filter (inside handle)
NPump
OInlet Valve
P Outlet Valve (airless hose connection)
Q Airless Hose
S Pail Hanger
T Inlet Screen
U Power Cord
Model/Serial Tag (Not shown, located
on bottom of unit.)
See Quick Reference, page 30 for more
information.
