Graco Merkur series User Manual

Installation
332245G 9
7. Close bleed type master air valve (C). Connect air
supply hose to air inlet.
8. Flush before using. See page 11.
9. Prime before using. See page 12.
Wet Cup
Before starting, fill wet cup (N) 1/2 full with Graco Throat
Seal Liquid (TSL) Part No. 206994, or compatible sol-
vent.
FIG. 4. Wet Cup
ti21105a
C
N
