Models
Models
A PR70 system can be ordered with many different options from the configurator below. The example PR70
system part number illustrated below contains the highlighted choices from the charts on pages 3 - 6.
PR70 - 2 - BT - BF - A - A7 - A4 - 2 - 3 - 1 - 1 - N - 2 - N - N - N - 2 - N - N - N
Code : A B-C D-E F G-H I-J K L M N O P Q R S T U V W
Motor
High Volume Piston
Low Volume Piston
Check Valve
High Volume Hose
Low Volume Hose
Dispense Valve
Mixer
Applicator Mounting
Power Cord
Pressure Transducers
High Volume Tank
High Volume Lib
Low Volume Tank
Low Volume Lib
Low Level Sensors
Heat Controller
Wet Test
Off-board Tank Stand
The following configuration P/N was assigned to the machine shipped with this manual:
PR70- - - - - - - - - - - - - - - - - - -
Code : A B-C D-E F G-H I-J K L M N O P Q R S T U V W
The following part number fields apply for PR70 part numbering Configurator process. Items highlighted in italics,
refer to “Super Standard” items with are typically stocked, and provide the best delivery dates.
2007 Product Configurator - PR70
Code A
Air Motor Information
1 3.0" (4,560mm2) Air Motor
2 4.5" (10,260mm2) Air Motor
3 3.0" Air Motor with hydracheck
4 4.5" Air Motor with hydracheck
5 Electric Drive
Code B High Volume Piston Material
Code D
Low Volume Piston Material
A Nylon A Nylon
B UHMWPE B UHMWPE
Code C High Volume Piston Size
Code E Low Volume Piston Size
1
80, Nylon Only, Super Standard
1
80, Nylon Only, Super Standard
2 100, Nylon Only 2 100, Nylon Only
3
120, Nylon Only, Super Standard
3
120, Nylon Only, Super Standard
4 140, Nylon Only 4 140, Nylon Only
5
160, Super Standard
5
160, Super Standard
6 180 6 180
7 200 7 200
8 220 8 220
9
240, Super Standard
9
240, Super Standard
A 260 A 260
B 280 B 280
C 300 C 300
F
320, Super Standard
F
320, Super Standard
G 360 G 360
H 400 H 400
J 440 J 440
L
480, Super Standard
L
480, Super Standard
M 520 M 520
R 560 R 560
S 600 S 600
T
640, Super Standard
T
640, Super Standard
U 720 U 720
W 800 W 800
X 880 X 880
Y
960, Super Standard
Y
960, Super Standard
Z Custom Low Volume Side, consult factory (SST Only)
312393C 3 of 52
