Parts
50 312760Y
* Not shown.
 Replacement Danger and Warning labels, tags, and
cards are available at no cost.
Ref Part Description Qty
2401 119912 SCREW, machined, phillips
pan head
2
2402 107596 SCREW, cap, hex head 1
2403 116193 PIN, dowel, 1/4 x 3/4 4
2404 120599 PIN, dowel 4
2405 120885 SCREW 2
2406 120886 SCREW 6
2407 120913 SCREW 6
2408 120918 BEARING, linear, slide 1
2409 121167 SCREW 6
2410 121518 SCREW, socket head cap 4
2411 121524 RING, retaining 2
2412 121529 RING, retaining,1-1/8 in., snap 2
2413 121530 SCREW, set, socket head
cap, M4 x 5, cone point
2
2414 256264 BLOCK, assembly, slide,
beam, ratio
2
2415 256268 CARRIAGE, assembly, slide,
beam, ratio
1
2416 256280 ARM, assembly, adjustment 1
2417 256288 KNOB, ratio adjustment 1
2418 15G747 MAGNET, linear sensor 1
2419 15K801 ROD, alignment 2
2420 15K802 RETAINER, nut 2
2421 15K868 WASHER, female, male modi-
fied, assembly
2
2422 15T377 BAR, ratio, beam 1
2423 15T383 PIN, pivot, beam, ratio 1
2424 15T384 PLATE, guide, ratio 2
2425 15T385 STUD, clevis, beam 4
2426 15T388 RETAINER, knob, adjust 1
2427 15T389 BRACKET, mounting, magnet 1
2428 15T448 CLEVIS, moving, machined 1
2429 15T449 CLEVIS, fixed, machined 1
2430 15T463 BRACKET, bar, pivot 1
2431 15T626 FRAME, base, machined 1
2432 15T715 NUT, locking, ratio adjustment 1
2433 LC0234 SENSOR, assembly 1
2434 119438 WASHER, flat 1
2435 15U196 BEARING, strip 4
2436 121573 BUMPER, urethane, 3/8-16 4
2499  * 84/0130-
27/11
LABEL, warning, pinch point 1
Ref Part Description Qty
