Repair
312760Y 29
Repair
HydraCheck Kit Installation
FIG. 7: HydraCheck Installation - Variable Ratio Base
203
200b
200a
200c
200d
Torque to 85 in-lb (9.6 N•m).
1
1
ti12437a
AA
FIG. 8: HydraCheck Installation - Fixed Ratio Base
100d
100b
420
103
104
ti12436a
