Graco PR70 - Shot Number Selection Lines

Parts
52 312760Y
† When replacing the muffler, adjust the muffler setting
so that the pistons take approximately 1/2 to 1 sec-
ond to retract.
Ref Part Description Qty
401 107571 PACKING, o-ring 1
402 114100 SCREW, cap, socket hd 3
403 120875 O-RING, 3 in. (assemblies LC0110
and LC0230)
1
104131 O-RING, 4.5 in. (assemblies
LC0111 and LC0231)
1
404 120880 SCREW 4
405 120881 BEARING 1
406 120884 SCREW 1
407 120899 VALVE, solenoid, 3 way 1
408 120900 VALVE, solenoid, 3 way 1
409 † 120922 MUFFLER, w/ integral flow control 1
410 120923 FITTING, elbow, male, swivel 1
411 120932 O-RING (assemblies LC0110 and
LC0230 only)
2
104271 PACKING, o-ring (assemblies
LC0111 and LC0231 only)
2
412 121018 FITTING, elbow, male, swivel,
1/4 npt
5
413 121020 FITTING, elbow, male, swivel,
1/4 npt
1
414 121021 MUFFLER, 1/4 npt 3
415 121022 FITTING, elbow, male, 1/4 npt 2
416 15K790 TUBE, air, cylinder, 3.0 (assem-
blies LC0110 and LC0230 only)
1
15K789 TUBE, air, cylinder, 4.5 (assem-
blies LC0111 and LC0231 only)
1
417 15K791 BLOCK, air cylinder, rod end 1
418 15K792 BLOCK, air cylinder, blind end 1
419 15K793 PISTON (assemblies LC0110 and
LC0230 only)
1
15K794 PISTON (assemblies LC0111 and
LC0231 only)
1
420 15K795 ROD, piston, air cylinder (assem-
blies LC0110 and LC0111 only)
1
15T714 ROD, piston, air cylinder (assem-
blies LC0230 and LC0231 only)
1
422 121643 FITTING, elbow, 1/4 x 1/4 npt,
swivel, ext (assemblies LC0230
and LC0231 only)
1
