Parts
312760Y 65
Lever Actuated MD2 Valves, LC0121 and LC0123
† See MD2 manual for dispense valve and dispense valve lever parts information. See Related Manuals on
page 3.
1101b
1101a
1103
1102
ti12441a
Assembly LC0121 Shown
Ref Part Description Qty
1101 LC0005 VALVE, assembly, 1:1, lever, electric
(assembly LC0121 only)
1
LC0007 VALVE, assembly, 10:1, lever, electric
(assembly LC0123 only)
1
1101a 255249 LEVER, 2K dispense valve 1
1101b † 255181 VALVE, dispense, 10:1, soft seats
(assembly LC0123 only)
1
† 255179 VALVE, dispense, 1:1, soft seats
(assembly LC0121 only)
1
1102 121198 CORD, euro, male, 4 pin, 3 wire, 6 m
(Series A Handles only)
1
123660 CORD, euro, male/female, 6 m
(Series B Handles only)
1
1103 120953 CONNECTOR, splitter 1
To Next Page
