On-Board Stainless Steel Feed Systems
Stainless Steel On-Board Lids
A. B. C.
D. E. F.
G. H. J.
Figure 26: Possible Stainless Steel Tank Lids
Key:
A. Dust Cover F. Clamp Down Lid w/ Electric Agitator, Degas and Fill Port
B. Clamp Down Lid G. Clamp Down Lid w/ Pneumatic Agitator
C. Clamp Down Lid w/Degas H. Clamp Down w/ Pneumatic Agitator and Degas
D. Clamp Down Lid w/ Electric Agitator
E. Clamp Down w/ Electric Agitator and Degas
J. Clamp Down Lid w/ Pneumatic Agitator, Degas and Fill
Port
312394B 25 of 71
