Graco PR70 - On-Board Polyethylene Feed Systems

On-Board Polyethylene Feed Systems
On-Board Polyethylene Feed Systems
Figure 2: On-Board Polyethylene Feed Systems
KEY:
A: Agitators (Optional) E: Ball Valve Shut-Off Assemblies (Optional)
B: Polyethylene Tank Lids F: Lid Clamp Assembly (Comes with Agitator Assembly)
C: 8L Dual Polyethylene Tank G: Low Level Sensors (Optional)
D: Liter Markers H: Lock Rings
CAUTION
• DO NOT HEAT THE POLYETHYLENE TANK ASSEMBLIES
• DO NOT PRESSURE FEED THE POLYETHYLENE TANK ASSEMBLIES
• DO NOT VACUUM DEGAS THE POLYETHYLENE TANK ASSEMBLIES
• DO NOT USE TANK ASSEMBLIES AS SUPPORT WHILE FILLING FROM
LARGER CONTAINERS
• CHECK THE BREATHERS ON THE LIDS REGULARLY TO ENSURE
THEY ARE NOT CLOGGED AND AIR IS FLOWING FREELY
312394B 7 of 71
