On-Board Stainless Steel Feed Systems
Be careful when interacting with the stainless steel feed systems because the contents and
surfaces may be hot if the system uses a heat package.
Read all the manufacturer’s warning and material MSDS to know the specific hazards of the
material used. Wear respirator, gloves and other protective clothing as necessary before
dispensing material.
Always unplug the agitators from their power source (electric or pneumatic) before
performing any maintenance.
Hearing protection may be required if sitting in close proximity to the pneumatic agitators.
Installation, Operation, Maintenance and Repair
1. If necessary, to remove tanks from pump housing,
loosen (Note: There is no need to completely
remove) the three (3) socket head cap screws that
hold each tank to the pump housing and rotate the
counter clockwise and lift the tanks off
2. If necessary, to remove tank and ball valve
assembly from pump housing, loosen (Note:
There is no need to completely remove) the three
(3) socket head cap screws that hold the tank to
the pump housing and rotate the whole tank and
ball valve assemblies counter clockwise and lift
the tanks off
Figure 27: Tank Removal From Housing Figure 28: Tank and Ball Valve Assembly Removal
From Pump Housing
312394B 26 of 71
