Calibration Screen
See Piston Position Calibration on page 38, Phasing
Adjustment on page 41, Adjust Open Dispense
Valve (ODV) Timing on page 44, and Shot Calibration
on page 48 for Calibration Screen use.
F
IG. 13
FA
Key:
FA Start/Stop Shot
FB Update Piston Extended Position
FC Update Piston Retracted Position
FD Update Piston Engaged Position
FE Piston Phasing
FF Adjust Open Dispense Valve Timing
FG Initiate Small Calibration Shot
FH Initiate Large Calibration Shot
FJ Active Screen Name
FK Adjacent Screen Names
FB
FC
FD
FE
FF
FG
FH
FJ
FK
FK
