Startup
22 312759W
Startup
1. Locate power switch (107) at rear of machine and
turn power on. The display module will automatically
turn on and begin to load.
2. Slide the system air pressure relief switch (106) up.
It is the yellow tab at the left, rear of the machine.
The hole in the tab should not be showing.
3. If the machine is in Disabled Mode, press the Select
Operating Mode button ( ) repeatedly to exit
Disabled mode and to select a new operating mode.
Press the Enter button ( ) to accept the new
operating mode.
FIG. 9: Disabled Mode
