Product Configurator
312759W 5
Code B Part
High Volume Side Piston and
Metering Tube Material
A LC1___ Nylon Piston, Stainless Steel Metering
Tube (last three digits of part number is
the mm
2
piston size)
B LC2___ UHMWPE Piston, Stainless Steel
Metering Tube (last three digits of part
number is the mm
2
piston size)
C LC3___ UHMWPE Piston, Ceramic Metering
Tube (last three digits of part number is
the mm
2
piston size)
Code C Part High Volume Piston Size (mm
2
)
1 80, Available in Nylon Only
2 100, Available in Nylon Only
3 120, Available in Nylon Only
4 140, Available in Nylon Only
5 160
6 180
7 200
8 220
9 240
A 260
B 280
C 300
F 320
G 360
H 400
J 440
L 480
M 520
R 560
S 600
T 640
U 720
W 800
X 880
Y 960
Z Custom High Volume side, consult fac-
tory (stainless steel only)
Code D Part
Low Volume Side Piston and
Metering Tube Material
A LC1___ Nylon Piston, Stainless Steel Metering
Tube (last three digits of part number is
the mm
2
piston size)
B LC2___ UHMWPE Piston, Stainless Steel
Metering Tube (last three digits of part
number is the mm
2
piston size)
C LC3___ UHMWPE Piston, Ceramic Metering
Tube (last three digits of part number is
the mm
2
piston size)
Code E Part Low Volume Side Piston Size (mm
2
)
1 80, Available in Nylon Only
2 100, Available in Nylon Only
3 120, Available in Nylon Only
4 140, Available in Nylon Only
5 160
6180
7200
8220
9 240
A260
B280
C300
F 320
G360
H400
J440
L 480
M520
R560
S600
T 640
U720
W800
X880
Y 960
Z Custom Low Volume side, consult fac-
tory (stainless steel only)
Code F Part Controls
B LC0272 Standard Display Module with 1 Fluid
Control Module
D LC0274 Advanced Display Module with 1 Fluid
Control Module
E LC0275 Advanced Display Module with 2 Fluid
Control Modules
Codes
G-H,
I-J
Part
High Volume Hose /
Low Volume Hose
A1 LC0801 3/16 in. (4.8 mm) - 2.5 ft (0.6 m)
A2 LC0802 3/16 in. (4.8 mm) - 10 ft (3.0 m)
A3 LC0803 3/16 in. (4.8 mm) - 15 ft (4.6 m)
A4 LC0804 1/4 in. (6.5 mm) - 2.5 ft (0.6 m)
A5 LC0805 1/4 in. (6.5 mm) - 10 ft (3.0 m)
A6 LC0806 1/4 in. (6.5 mm) - 15 ft (4.6 m)
A7 LC0807 3/8 in. (9.5 mm) - 2.5 ft (0.6 m)
A8 LC0808 3/8 in. (9.5 mm) - 10 ft (3.0 m)
A9 LC0809 3/8 in. (9.5 mm) - 15 ft (4.6 m)
AA LC0810 1/2 in. (13 mm) - 2.5 ft (0.6 m)
AB LC0811 1/2 in. (13 mm) - 10 ft (3.0 m)
AC LC0812 1/2 in. (13 mm) - 15 ft (4.6 m)
AG LC0813 3/4 in. (19 mm) - 10 ft (3.0 m)
