Troubleshooting
312759W 73
F2B-Low Flow B Side Low B Side Fluid Flow, relative to calibra-
tion and user-input allowable variance.
See Dispense Check Options, Screen
#4 on page 32.
6
F2FX-D-Delta Velocity Minus Delta Velocity Minus 6
F3FX-D-Delta Velocity Plus Delta Velocity Plus 6
F6A-Flow Meter A Problem Flow Meter A Problem, or bad connection
between Fluid Control Module and Flow
Meter A
6
F6B-Flow Meter B Problem Flow Meter B Problem, or bad connection
between Fluid Control Module and Flow
Meter B
6
L2AX-D-Low Level Tank A Low Material Level, Tank A 6
L2BX-D-Low Level Tank B Low Material Level, Tank B 6
L2FX-D-Low Level Tank A/B Low Material Level, Both Tanks 6
L8AX-D-Refill Timeout A Auto Refill Failed, A Side 6
L8AX-D-Refill Timeout B Auto Refill Failed, B Side 6
P2AX-D-Low Pressure A A Side Low Pressure, relative to calibra-
tion and user-input allowable variance.
See Dispense Check Options, Screen
#4 on page 32.
6
P2BX-D-Low Pressure B B Side Low Pressure, relative to calibra-
tion and user-input allowable variance.
See Dispense Check Options, Screen
#4 on page 32.
6
P3AX-D-High Pressure A A Side High Pressure, relative to calibra-
tion and user-input allowable variance.
See Dispense Check Options, Screen
#4 on page 32.
6
P3BX-D-High Pressure B B Side High Pressure, relative to calibra-
tion and user-input allowable variance.
See Dispense Check Options, Screen
#4 on page 32.
6
P6AX-D-Pressure Fault A Problem with A Side Piston Pressure
Transducer or Transducer Connection
6
P6BX-D-Pressure Fault B Problem with B Side Piston Pressure
Transducer or Transducer Connection
6
P6DX-D-Pressure Fault A/B Problem with A and B Side Piston Pres-
sure Transducer or Transducer Connec-
tion
6
Code-Class-Event
Shown on Errors Screen Description
System
Behavior Ref
