Technical Specifications
36 3A4702E
Technical Specifications
HandHeld Sprayer
U.S. Metric
Max Working Pressure 2000 psi 14 MPa, 138bar
Maximum Amperage
3.6 Amps 3.6 Amps
Weight
4.6 lb 2.1 kg
Dimensions:
Length
14.0 in. 36.1 cm
Width
5 in. 12.7 cm
Height
10.5 in. 26.7 cm
Storage Temperature Range ◆
❖
32° to 113° F 0° to 45° C
Operating Temperature Range
✓
40° to 90° F 4° to 32° C
Storage Humidity Range 0% to 95% relative humidity, non-condensing
Sound Pressure Level
85.1 dBa
Sound Power Level † 90.0 dBa, Uncertainty K = 0.5 dBa
Vibration level (measured in
accordance with EN50580:2012)
Vibration total value
a
h
= 21.5 ft/s
2
Uncertainty = 0.3 ft/s
2
Vibration total value
a
h
= 6.5 m/s
2
Uncertainty = 0.1 m/s
2
Power Cord 18 AWG, 3-wire
1.0 mm
2
, 3-wire
Length
18 in. 45.7 cm
Electrical Power Requirement
120 Vac, 60 Hz, 15A, 1 Ø
Maximum tip orifice
0.016 in. 0.41 mm
◆ Pump damage will occur if fluid freezes in pump.
❖ Damage to plastic parts may result if impact occurs in low temperature conditions.
✓ Changes in paint viscosity at very low or very high temperatures can affect sprayer
performance.
† All readings were taken within the priming mode at the assumed operator position. Sound
power levels were tested to ISO 3741 at 3.3 feet (1m).
