Pressure Relief Procedure
14 310665E
Pressure Relief
Procedure
Fluid Manifold to Gun
WARNING
Relieve pressure from fluid manifold to gun whenever
you stop spraying and before servicing gun or remov-
ing spray tip.
In addition, relieve pressure from pump to fluid mani-
fold at end of day and before cleaning, checking, or
servicing pump, manifold, or fluid line accessories or
transporting equipment.
Read warnings, page 5.
1. Engage trigger lock.
TI5049a
2. Press .
3. Disengage trigger lock.
4. Hold a metal part of the gun firmly to a grounded
metal pail. Trigger gun to relieve pressure.
5. Engage trigger lock.
TI5048a
TI5046a
TI5049a
To Next Page
