Repair

Calibration Calibration

Calibration

Procedure Procedure

Procedure

NOTICE NOTICE

NOTICE

Topreventdamagetotheheatedhose,ahose

calibrationisrequiredifanyofthefollowing

conditionsaretrue:

•Thehosehasneverbeencalibratedbefore.

•Asectionofhosehasbeenreplaced.

•Asectionofhosehasbeenadded.

•Asectionofhosehasbeenremoved.

NOTE: NOTE:

NOTE:

TheReactorandheatedhosemustbeatthe

sameambienttemperaturetogetthemostaccurate

calibration.

1.EnterSetupModeandnavigatetoSystem

screen3,thenpresstheCalibratesoftkey

2.PresstheContinuesoftkeytoacknowledge

theremindertohavethehoseatambient

conditions.

3.Waitwhilethesystemmeasuresthehose

resistance.

NOTE: NOTE:

NOTE:

Ifhoseheatwasonpriortothecalibration

procedure,thesystemwillwaitupto󰘰veminutes

toallowthewiretemperaturetoequalize.

NOTE: NOTE:

NOTE:

Thehosetemperaturemustbeabove32

°F(0°C)duringcalibration.
