Repair

Repair Repair

Repair

Proportioning Proportioning

Proportioning

Pumps Pumps

Pumps

1.FollowBeforeBeginningRepair,page50.

2.TurnbothPressureRelief/Sprayvalve(SA,SB)

toPressureRelif/Circulation.Route󰘱uidtowaste

containersorsupplytanks.Ensuregauges(GA,

GB)dropto0psi.

NOTE: NOTE:

NOTE:

Usedropclothorragstoprotectthe

Reactorandsurroundingareafromspills.

3.DisconnecttheB(Resin)sidepumpinletline,the

inlety-strainer,andhardtube(57).Removethe

pin(213)fromtheclevis(317)todisconnectthe

pumpfromthehydrauliccylinder(201).Remove

thefourscrews(203)holdingthepumptothe

spacers(313)ofthecylinder.Takethepump

assemblytoaworkbench.

Torque to 200 in. - lb (22.6 N•m).

4.DisconnecttheA(ISO)sidepumpinletline,the

inlety-strainer,andhardtube(55).Usethepin

extractortool(101)toremovethepin(213),which

disconnectsthepumpfromthehydrauliccylinder

(201).Removethefourscrews(203)holdingthe

pumptothespacers(313)ofthecylinder.Take

thepumpassemblytoaworkbench.

Torque to 200 in. - lb (22.6 N•m).

5.Seepumpmanualforrepairinstructions.

6.Reconnectthepumpinthereverseorder.Torque

thescrewsto200in.-lb(22.6N•m)

52 334946H
