Graco Reactor 2 H-30 Repair Parts

Repair
Replace Replace
Replace
Electric Electric
Electric
Motor Motor
Motor
Remove Remove
Remove
NOTICE NOTICE
NOTICE
Becarefulnottodropordamagethemotor.The
motorisheavyandmayrequiretwopeopletolift.
1.FollowShutdown,page48.
2.Openelectricalenclosure.Disconnectthe
AsideheaterconnectorfromtheTCM.See
ElectricalSchematics,page102.Closethe
electricalenclosuredoor.
3.Removemountingboltsfromthebottomframe
andmovethesystemawayfromthewall.
Figure2
4.Removeupperbolts(3).Tilttheelectrical
enclosuredowntogainaccesstothemotor
cover.
5.Removemotorandbeltcovers(123,131,132).
Liftcover(132)andloosenthebluebracket(131)
fasteners.Liftthebluebracket(133)offofthe
fastenersandsetaside.Removethebeltcovers
(131,132).
Figure3MotorandBeltCovers
Figure4HeaterandBeltCovers
56 334946H
