AdvancedDisplayModule(ADM)

Icons Icons

Icons

Icon Icon

Icon

Function Function

Function

ComponentA

ComponentB

EstimatedSupplyMaterial

Pressure

CycleCounter(pressand

hold)

Advisory.

SeeTroubleshootErrors,

page67formoreinformation.

Deviation.

SeeTroubleshootErrors,

page67formoreinformation.

Icon Icon

Icon

Function Function

Function

Alarm.

SeeTroubleshootErrors,

page67formoreinformation.

PumpMovingLeft

PumpMovingRight

HoseTemperatureinHose

FTSMode

HoseTemperatureinHose

ResistanceMode

HoseAmpsinManualMode

334945J 25
