Graco Reactor 2 H-XP3 User Manual

AdvancedDisplayModule(ADM)
Soft Soft
Soft
Keys Keys
Keys
Iconsnexttothesoftkeysindicatewhichmodeor
actionisassociatedwitheachsoftkey.Softkeys
thatdonothaveaniconnexttothemarenotactive
inthecurrentscreen.
NOTICE NOTICE
NOTICE
Topreventdamagetothesoftkeybuttons,donot
pressbuttonswithsharpobjectssuchaspens,
plasticcards,or󰘰ngernails.
Icon Icon
Icon
Function Function
Function
StartProportioner
StopProportioner
Turnonoroffthespeci󰘰edheatzone.
Parkpump
ResetCycleCounter
(pressandhold)
SelectRecipe
Search
MoveCursorLeftOneCharacter
MoveCursorRightOneCharacter
Icon Icon
Icon
Function Function
Function
Togglebetweenupper-case,lower-case,
andnumbersandspecialcharacters.
Backspace
Cancel
Clear
TroubleshootSelectedError
Increasevalue
Decreasevalue
Nextscreen
Previousscreen
Returnto󰘰rstscreen
Calibrate
Continue
