Graco Reactor 2 H-XP3

Startup
9.Switchontheaircompressor,airdryer,and
breathingair,ifincluded.
10.For󰘰rststartupofnewsystem,load󰘱uidwith
feedpumps.
a.CheckthatallSetup Setup
Setup
stepsarecomplete.
SeeSetupMode.
b.Ifanagitatorisused,opentheagitator’sair
inletvalve.
c.Ifyouneedtocirculate󰘱uidthroughthe
systemtopreheatthedrumsupply,see
CirculationThroughReactor,page50.
Ifyouneedtocirculatematerialthrough
theheathosetothegunmanifold,see
CirculationThroughGunManifold,page51.
d.TurnbothPRESSURERELIEF/SPRAY
valves(SA,SB)toSPRAY
.
e.Open󰘱uidinletvalves(FV).Checkforleaks.
Cross-contaminationcanresultincured
materialin󰘱uidlineswhichcouldcause
seriousinjuryordamageequipment.To
preventcross-contamination:
•Never Never
Never
interchangecomponentAand
componentBwettedparts.
•Neverusesolventononesideifit
hasbeencontaminatedfromtheother
side.
•Alwaysprovidetwogroundedwaste
containerstokeepcomponentAand
componentB󰘱uidsseparate.
f.Holdgun󰘱uidmanifoldovertwogrounded
wastecontainers.Open󰘱uidvalvesAandB
untilclean,air-free󰘱uidcomesfromvalves.
Closevalves.
The Fusion AP gun manifold is shown.
48 334945J
