USB Data
Daily Log
The daily log file name is 3–DAILY.CSV and is stored
in the DATAxxxx folder.
The dail y log maintains a record of the tota l c ycle
and volume sprayed on any day that the system is
powered up. The volume units will be the same units
that were used in the Job Log.
The following data is stored in this file:
• Date that material was sprayed
• Time — unused column
• Total pump cyc le co unt for day
• Total volume sprayed for day
System Software Log
The system software file name is 4–SYSTEM.CSV
andisstoredintheDATAxxxxfolder.
The system software log lists the following:
• Date log was created
• Time l og was created
• Component name
• Software version loaded on the above component
Blackbox Log File
The black box file name is 5–BLA C KB.CSV and is
stored in the DATAxxxx folder.
The Blackbox log maintains a record of how the
system runs and the features that are used. This log
will help Graco troubleshoot system errors.
Diagnostics Log File
The diagnostics file name i s 6–DIAGNO.CSV and is
stored in the DATAxxxx folder.
The Diagnostics log maintains a record of how the
system runs and the features that are used. This log
will help Graco troubleshoot system errors.
System Configuration Settings
The system configuration settings file name is
SETTIN GS.TXT and is stored in the DOWNLOAD
fold er.
A system configuration settings file automatically
downloads each time a USB flash drive is inserted
into the ADM. Use this file to back up system
settings for future recovery or to easily replicate
settings across multiple systems. Refer to the
Upload Procedure, page 80 for instructions on how
to use this file.
78 332636D
