Graco Reactor A-20 User Manual

Systems
311511G 3
Systems
253831 Proportioner
This model is field-configurable to the following supply
voltages:
230 V, 1 Phase
230 V, 3 Phase
380 V, 3 Phase
2,000 psi (14 MPa,140 bar) Maximum Fluid Working Pressure
120 psi (0.84 MPa, 8.4 bar) Maximum Air Working Pressure
Approvals:
System Part
Maximum Fluid
Working Pressure
psi
(MPa, bar) Proportioner
Heated Hose Gun
50 ft (15 m) 10 ft (3 m) Model Part
AP3831 2000
(13.8, 138)
253831 246678 246050 Fusion Air
Purge
246101
CS3831 2000
(13.8, 138)
253831 246678 246050 Fusion CS CS01RD
P23831 2000
(13.8, 138)
253831 246678 246050 Probler P2 GCP2R1

#ONFORMSTO!.3)5,
3TD#ERTIFIEDTO
#!.#3!3TD
#.O
