Graco Reactor A-20 - Typical Installation; Without Circulation

Typical Installation, without Circulation
311511G 7
Typical Installation, without Circulation
Key for FIG. 1
A Reactor Proportioner
BHeated Hose
C Fluid Temperature Sensor (FTS)
D Heated Whip Hose
E Fusion Spray Gun
F Proportioner and Gun Air Supply Hose
G Feed Pump Air Supply Lines
H Waste Containers
J Fluid Supply Lines
K Feed Pumps
L Agitator
M Desiccant Dryer
N Bleed Lines/Over Pressure Relief
P Gun Fluid Manifold
FIG. 1: Typical Installation, without Circulation
A
B
C*
D
E
K
L
M
F
P
N
* Shown exposed for clarity. Wrap with tape during operation.
K
H
J
G
ti8489a
