Category Data
Maximum Fluid Working Pressure Models E-20 and E-30: 2000 psi (14 MPa, 140 bar)
Model E-XP1: 2500 psi (17.2 MPa, 172 bar)
Model E-XP2: 3500 psi (24.1 MPa, 241 bar)
Maximum Fluid Temperature 190°F (88°C)
Maximum Output Model E-20: 20 lb/min (9 kg/min)
Model E-30: 30 lb/min (13.5 kg/min)
Model E-XP1: 1 gpm (3.8 liter/min)
Model E-XP2: 2 gpm (7.6 liter/min)
Output per Cycle (A and B) Model E-20 and E-XP1: .0104 gal. (.0395 liter)
Model E-30: .0272 gal. (0.1034 liter)
Model E-XP2: .0203 gal. (.0771 liter)
Line Voltage Requirement Part Nos. 246024, 246025, 246026, 246028: 195-264 Vac, 50/60 Hz
Part Nos. 246029, 246030, 246031, 246032: 338-457 Vac, 50/60 Hz
Part Nos. 246033, 246034, 246035, 246036: 195-264 Vac, 50/60 Hz
Amperage Requirement See page 3.
Heater Power Model E-20: 6000 Watts
Model E-30 and E-XP1: 10200 Watts
Model E-XP2: 15300 Watts
Sound Power, per ISO 9614-2 Model E-20: 80 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Model E-30: 93.5 dB(A) at 1000 psi (7 MPa, 70 bar), 3.0 gpm (11.4 lpm)
Model E-XP1: 80 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Model E-XP2: 83.5 dB(A) at 3000 psi (21 MPa, 210 bar), 1.0 gpm (3.8 lpm)
Sound Pressure, 1 m from equipment Model E-20: 70.2 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Model E-30: 83.6 dB(A) at 1000 psi (7 MPa, 70 bar), 3.0 gpm (11.4 lpm)
Model E-XP1: 70.2 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)
Model E-XP2: 73.6 dB(A) at 3000 psi (21 MPa, 210 bar), 1.0 gpm (3.8 lpm)
Fluid Inlets 3/4 npt(f), with 3/4 npsm(f) union
Fluid Outlets Component A (ISO): #8 JIC (3/4-16 unf), with #5 JIC adapter
Component B (RES): #10 JIC (7/8-14 unf), with #6 JIC adapter
Fluid Circulation Ports 1/4 npsm(m), with plastic tubing
Weight Model E-20 and E-XP1: 342 lb (155 kg)
Model E-30: 400 lb (181 kg)
Model E-XP2: 438 lb (198 kg)
Wetted Parts Aluminum, stainless steel, carbon steel, brass, carbide, chrome, chemically
resistant o-rings, ultra-high molecular weight polyethylene
