Repair
Repair Repair
Repair
Repairingthisequipmentrequiresaccesstoparts
thatmaycauseelectricshockorotherseriousinjury
ifworkisnotperformedproperly.Besuretoshut
offallpowertoequipmentbeforerepairing.
Before Before
Before
Beginning Beginning
Beginning
Repair Repair
Repair
NOTICE NOTICE
NOTICE
Propersystemsetup,startup,andshutdown
proceduresarecriticaltoelectricalequipment
reliability.Thefollowingproceduresensuresteady
voltage.Failuretofollowtheseprocedureswill
causevoltage󰘱uctuationsthatcandamage
electricalequipmentandvoidthewarranty.
1.Flushifnecessary.SeeFlushing,page49.
2.SeeShutdown,page48.
Pumpline Pumpline
Pumpline
Disassembly Disassembly
Disassembly
1.FollowthePressureReliefProcedure,page47.
2.Removeplug󰘰tting(206)fromlubecylinder
(205).
3.Insertclevispinremovaltool296607through
openinginlubecylinder(205)andscrewtoolinto
leftclevispin(219).Pullclevispinoutofclevis
(117).
4.Usehexkeytoremovefoursocketheadcap
screws(203)fromleftproportioningpump(202).
Removeleftproportioningpump.
5.Removelubecylinder(205).
6.Screwpinremovaltool296607intorightclevis
pin(219).Pullclevispinoutofclevis(117).
7.Usehexkeytoremovefoursocketheadcap
screws(203)onrightproportioningpump(202).
Removerightproportioningpump.
50 334946H
