Graco RTX5000 User Manual

Technical Specifications
3A3265B 33
Technical Specifications
US Metric
Sprayer
Material Hopper Capacity
15 gal 57 l
Maximum Delivery with Texture
RTX5000
5.0 gpm 18.9 lpm
RTX5500
5.5 gpm 20.8 lpm
Maximum Fluid Working Pressure 100 psi 6.9 bar, 0.7 MPa
Maximum Air Working Pressure 50 psi 3.5 bar, 0.35 MPa
Compressor Air Displacement
RTX5000PI
15A @ 110
–120V or 6.6 cfm @ 20 psi 187 l/m @ 1.3 bar, 0.13 MPa
20A @ 110
–120V 8.6 cfm @ 20 psi 244 l/m @ 1.7 bar, 0.17 MPa
RTX5500PI
10A @ 220–230V or
16A @ 220–230V
7.7 cfm @ 20 psi
9.1 cfm @ 20 psi
218 l/m @ 1.5 bar, 0.15 MPa
258 l/m @ 1.8 bar, 0.18 MPa
Compressor Specifications Belt drive oil-less
Electric Motor DC brush less
RTX5000PI 15A @ 110
–120V or
20A @ 110
–120V
RTX5500PI 10A @ 220–230V or
16A @ 220–230V
Power Cord
RTX5000 12 AWG, 3-wire, 25 ft
RTX5500 14 AWG, 3-wire, 25 ft
Generator Minimum 7500 W
Power Requirements
110–120V, 15/20 A, 1Ø
220–230V, 10/16 A, 1Ø
Dimensions
Height 39.5 in. 100 cm
Length
33.75 in. 86 cm
Width
22.75 in. 58 cm
Weight (includes hose and gun)
RTX5000PI/RTX5500PI
164 lb. 74.4 kg
RTX5000PX/RTX5500PX
174 lb. 78.9 kg
Weight (gun) 2.3 lb. 1.0 kg
Storage temperature range 
–35° to 160°F –1.6° to 71°C
Operating temperature range 
40° to 115°F 4° to 46°C

Graco RTX5000 Specifications

General

Brand	Graco
Model	RTX5000
Category	Paint Sprayer
Language	English
