Graco Simulation XM Repair Parts

Electrical Schematics
34 3A2989V
Sensor Schematic Junction Box
Junction Box
Solenoid Module Tank Fill
2
1
6
75
Fluid Control FCM-1 289696 Base 289697
Sol
A
Sol B
262856
Solenoid
Cable 121806
Solenoid Cable 121806
Tank Level A
Cable 126494
Tank Level B Cable 126494
Level Sensor
24X090
Level Sensor
24X090
A
B
Level Sensor Cable 128026
Level Sensor Cable 128026
M12 Connector
SOL-
A
SOL-B
FCM1-1
FCM1-2
B TANK LEVE
L
A
TANK LEVE
L
1
2
1
2
Black
Silve
r
Splitter 126495
Splitter 124273
FCM1-7
FCM1-5
2-SILVER
1-BLACK
M12 Connector
Cord Grip
120858
Nut 120859
Door Ground Wire 194337
Flush Pump Ground 18 AWG Copper Wire
Frame Ground
T
erminal
117666
Pail Ground 14 AWG Copper Wire
238909
18 AWG Copper Wire
