Electrical Schematics
3A2989V 35
Sensors Schematic Control Box
Control Box
Fluid Control
FCM-2 255920
DM Front
255727
Display
Module
288997
1
2
NC
Switch Key 121617
Switch Latch 120493
Switch Block NC 120495
Setup Key
Switch Cable
15M974
3
4
NC
1
2
NO
Switch Start Green 121618
Switch Latch 120493
Switch Block NO 120494
Switch Stop Red 121619
Switch Latch 120493
Switch Block NC 120495
A
larm Buzzer
122000
Pressure Sensor A 15M669
O-Ring 121399
Pressure Sensor B 15M669
O-Ring 121399
Tank RTD A 126381
Compression Fitting 126351
Tank RTD B 126381
Compression Fitting 126351
Linear Sensor B 256893
A
ir Motor A Cable 15U542
Reed Switch B 119700
Junction Box NXT411
Linear Sensor A 256893
Reed Switch A 119700
Junction Box NXT411
Solenoid Module 256555
Solenoid 121636
Stop Switch
Cable 15M976
B
Green
A
Blue
Start Switch
Cable 15M975
S1-BLACK
S1-BLUE
S2-BLACK
S2-BLUE
Blue
Black
Red
Black
A
A
B
B
Dose
Motor
Dose
Motor
Motor
A
Dosing Valve A
Motor B
Dosing Valve B
USB
289900
Base
289899
USB Extension
Cable 15R324
Cover 15R325
Solenoid A Cable 15M977
Solenoid B Cable 15M977
A
ir Motor B Cable 15U542
M8 Connectors
M8 Connectors
Extension
Cable 121683
Extension
Cable 121683
Door Ground
Wire 15B090
FCM-2
Ground Wire
5
4
3
2
1
5
4
3
2
1
18 AWG Copper Wire
18 AWG
Copper Wire
