Graco Standard Series

Component Identification
12 334606B
Component Identification
ProContractor Models (EH/GH
™
230, 300)
3.
13.
2.
12.
7.
OFF
ON
on
off
bar/MPa
PSI
8.
OI
4.
1.
11.
9.
10.
5.
6.
14.
15.
16. 17.
ti25308a
18.
1 Pressure Gauge
2 Pressure Control
3 Hydraulic Pump Valve
4 ProConnect
5 Displacement Pump
6 Inlet Strainer
7 Engine On/Off Switch
8 Engine Controls
9 Electric Motor On/Off Switch
10 GunTrigger Lock
11 Grounding Clamp
12 Serial Number Tag
13 Prime/Drain Valve
14 Hydraulic Oil Cap / Dipstick
15 Hose Reel Lock
16 Hose Reel Handle
17 Hydraulic Oil Filter
18 Paint Filter
