Technical Data
64 334606B
DutyMax EH230DI ProContractor Series
US Metric
Maximum fluid working pressure. . . . . . . . . 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity . . . . . . . . . . . . 1.25 gallons 4.75 liters
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.0 HP
2.2 kW
Voltage, Amperage Frequency Phase
220 VAC, 15.0 A,
50 Hz, 1 phase
220 VAC, 15.0 A
50 Hz, 1 phase
Maximum tip size. . . . . . . . . . . . . . . . . . . . . 0.039
Maximum free-flow delivery. . . . . . . . . . . . . 1.56 gpm 5.9 l/min
Hose connection . . . . . . . . . . . . . . . . . . . . . 3/8 npsm (f)
Cycles per gallon 80 21.1
Sound Levels
(Measured at maximum normal load conditions)
Engine HP . . . . . . . . . . . . . . . . . . . . . . . . . .
3.0
Sound pressure
80 dBa
Sound power
95
Inlet/Outlet Sizes
Fluid inlet size in.. . . . . . . . . . . . . . . . . . . . . 1 npt (m)
Fluid outlet size in.. . . . . . . . . . . . . . . . . . . . 3/8 npt (m)
Weight
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227 lbs. 103 kg
Width
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26.5 in. 67 cm
Length
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 in. 132 cm
Height
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 in. 99 cm
