Technical Data
334606B 61
Maximum back fuse rating for EH300DI:
Fuse type aM: 63A
Fuse type gL: 80 A
NOTE: Under voltage release coil in motor starter for EH300DI will not energize if voltage is less than 85%
of listed voltage in Technical Data table.
Under voltage release coil in motor starter for EH300DI will de-energize and sprayer will stop if voltage drops
to 85% of rated nominal voltage. Voltage will need to be increased and sprayer will need to be restarted.
NOTE: To operate the EH300DI (24M056) sprayer with a generator, the generator must be sized for 5 kW
output (minimum).
Basic Sprayer Wetted Parts:
Zinc and nickel-plated carbon steel, stainless steel, PTFE, acetal, chrome plating, leather, V-Max
UHMWPE, aluminum, tungsten carbide, ceramic, nylon
DutyMax EH300DI Standard Series
US Metric
Maximum fluid working pressure . . . . . . . . 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity . . . . . . . . . . . . 1.25 gallons 4.75 liters
Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.5 HP
5.5 kW
Voltage, Amperage Frequency Phase
400 VAC, 11.0 A,
50 Hz, 3 phase
400 VAC, 11.0 A
50 Hz, 3 phase
Maximum tip size . . . . . . . . . . . . . . . . . . . . 0.057
Maximum free-flow delivery . . . . . . . . . . . . 3.0 gpm 11.3 l/min
Hose connection. . . . . . . . . . . . . . . . . . . . . 1/2 npsm (f)
Cycles per gallon 52 13.7
Sound Levels
(Measured at maximum normal load conditions)
Engine HP . . . . . . . . . . . . . . . . . . . . . . . . .
7.4
Sound pressure
80 dBa
Sound power
95
Inlet/Outlet Sizes
Fluid inlet size in. . . . . . . . . . . . . . . . . . . . . 1 npt (m)
Fluid outlet size in. . . . . . . . . . . . . . . . . . . . 1/2 npt (m)
Weight
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236 lb. 107 kg
Width
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26.5 in. 67 cm
Length (Handle bar retracted)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47.7 in. 121 cm
Height (Handle bar retracted)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35.5 in. 90 cm
