Graco Standard Series User Manual

Technical Data
68 334606B
2.25 in.
(57.15 mm)
1.813 in.
(46.05 mm)
1.813 in.
(46.05 mm)
3/4 - 14
NPT Male
2.25 in.
(57.15 mm)
1.813 in.
(46.05 mm)
2.25 in.
(57.15 mm)
ti24313b
Hydraulic
Return,
37º flare,
3/4-16 UNF-2A
Hydraulic
Inlet, 37º flare,
3/4-16 UNF-2A
Mounting Screws (4),
ocket Cap Screw 1 in.
3/8-16 UNC
Paint Outlet,
90º swivel,
3/8-18 NPT Male
Paint Suction Fitting,
1-11 1/2 NPT Male
Hydraulic
Return,
37º flare,
3/4-16 UNF-2A
Hydraulic
Inlet, 37º flare,
3/4-16 UNF-2A
Mounting Screw (4),
Socket Cap Screw 1in.
3/8-16 UNC
Quick Connect
Quick Connect
Paint Outlet,
3/8-18 NPT Male
Paint Suction Fitting,
1.312-121/2 UN-2A
Hydraulic
Return,
37º flare,
3/4-16 UNF-2A
Hydraulic
Inlet, 37º flare,
3/4-16 UNF-2A
Mounting Screw (4),
Socket Cap Screw 1in
3/8-16 UNC
Paint Outlet,
3/8-18 NPT Male
Paint Suction Fitting,
1.312-12 UN-2A Male
GH130 OEM
GH200 OEM
GH230/300 OEM

Graco Standard Series Specifications

General

Maximum Pressure	3000 psi
Power Source	Electric
Type	Airless
Hose Length	50 ft
Series	Standard
