Parts
Pressure Pot 239023
Ref.
No. Part No. Description Qty.
1 239037 POT, pressure 1
Includes items 1a and 1b
1a 192019 .COVER, pressure pot modified 1
1b 114055 .VALVE, safety 1
2 100840 ELBOW, street, 1/4 in. npt 1
3 169970 FITTING, line, air, (m) 1
4 113373 WASHER, spring 10 mm 1
5 114045 GAUGE, press, air, 0 to 160 psi
0 to 1.1 MPa, 0 to 11 bar) 1
6 190938 GUARD, gauge 1
7 100469 CAPSCREW 1
8 239024 BAND, retaining, pressure pot 1
9 100731 WASHER 1
10 113120 NIPPLE, brass, 1 in. npt x 4 in. 1
11 113121 VALVE, ball 1
12 15D985 COUPLER, Female, 1 in. npt 1
13 113336 ADAPTER 1/4 in. npt (m x f) 1
14 113379 VALVE, vent, 1/4 in. x 1/4 in. 1
15 113096 MUFFLER, Valve, Ball 1
45 191947 FLOAT, tank 1
1b
15
14
13
6
8
5
2
3
11
10
4
7
9
1
12
1a
45
ti5085a
