Operation
3A9095C 21
Operation
Spray Tip Installation
1. Perform Pressure Relief Procedure,
page 14.
2. Use spray tip (A) to insert OneSeal
™
(B)
into tip guard (C).
3. Insert Spray Tip.
4. Screw assembly onto gun. Tighten.
Performance Modes
The sprayer is equipped with two spray
modes.
LP (Low Pressure) Mode (L): For use with
50-2,000 psi. This mode is best used with
Low Pressure Switch Tips (FFLP. LP, and
WRLP)
HP (High Pressure) Mode (H): For use with
600-3,300 psi. This mode is best used with
any Switch Tip.
To select or change the spray mode, see
Selecting Perfromance Modes, page 27.
To avoid serious injury from skin injection
do not put your hand in front of the spray
tip when installing or removing the spray
tip and tip guard.
