Wiring Diagram
311365H 43
Wiring Diagram
695/795 Lo-Boy Series B; 695 Hi-Boy Series D;
795 Hi-Boy Series C; 1095/1595/Mark V Series B
Potentiometer
Black
ON/OFF
Switch
Power Plug
Pressure
Transducer
Motor
Black +
white
green/ground
green/ground
Digital Display
Watchdog
Switch
14A 10A
1595/MARK V
ti7346a

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco ultra max ii and is the answer not in the manual?

Graco ultra max ii Specifications

General IconGeneral
Max Pressure3300 PSI
MotorOilless, axial cam
SeriesUltra Max II
Power SourceElectric
Voltage120V
Hose Length50 ft
TypeAirless
Max Tip Size0.017 inches
Spray Tip Size0.009 - 0.017 inches
