Wiring Diagram
44 311365H
Wiring Diagram
695/795 Lo-Boy Series B; 695 Hi-Boy Series D;
795 Hi-Boy Series C; 1095/1595/Mark V Series B
Black
Pressure
Transducer
Digital Display
ON/OFF
Switch
Power Plug
Black +
white
green/ground
Motor
green/ground
Potentiometer
1595 Switch
20A 15A
Watchdog
Black
ON
Dip Switch
ti12980a

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco ultra max ii and is the answer not in the manual?

Graco ultra max ii Specifications

General IconGeneral
Max Pressure3300 PSI
MotorOilless, axial cam
SeriesUltra Max II
Power SourceElectric
Voltage120V
Hose Length50 ft
TypeAirless
Max Tip Size0.017 inches
Spray Tip Size0.009 - 0.017 inches
