Dimensions
28 313292J
(50.80 mm)
2.000 in.
(456.44 mm)
17.970 in.
(79.50 mm)
3.130 in.
(404.37 mm)
15.920 in.
(19.05 mm)
0.750 in.
8 X FULL R .440
Air Control Assembly
(254.00 mm)
10.000 in.
(482.60 mm)
19.000 in.
(387.35 mm)
15.250 in.
(381.00 mm)
15.000 in.
(176.28 mm)
6.940 in.
4 X FULL R .500
Control Box Assembly
r_xma000_313292_8a
r_xma000_313292_7a
