XM Plural-Component OEM Sprayer
US Metric
Mixed ratio range 1:1-10:1 (in 0.1 increments)
Ratio tolerance range +/- 5%
Flow rates
Minimum
Maximum
1 qt./min.
3 gal./min.
0.95 liter/min.*
11.4 liter/min.
Fluid viscosity range 200-20,000 cps (heavier viscosities can be mixed using heat,
circulation, and/or pressure feeding)
Fluid filtration 60 mesh, (238 micron) standard on pump outlets (filter assembly
not included on some models)
Air inlet 3/4 npt(f)
Fluid inlets without feed kits 1 1/4 npt(m)
Ambient temperature range
Operating
Storage
32-135° F
30-160° F
0-57° C
-1-71° C
Maximum fluid working pressure of mixed material
50:1
70:1
5200 psi
6300 psi
35.8 MPa, 358 bar
43.5 MPa, 435 bar
Maximum fluid temperature 160° F 71° C
Air supply pressure range 50-150 psi 0.35-1.0 MPa, 3.5-10.3 bar
Maximum pump air set pressure
50:1
70:1
100 psi
90 psi
0.68 MPa, 6.8 bar
0.62 MPa, 6.2 bar
Maximum pump inlet fluid feed pressure 250 psi 1.7 MPa, 17 bar
Maximum air consumption at
100 psi (0.7 MPa, 7.0 bar) in scfm (m
^
3/min.)
70 scfm per gpm (1.96 m^3min. per lpm)
Noise dB(A)
Operating Pressure 70 psi (0.48 MPa, 4.8 bar)
Sound power 84.6 dB(A)
Sound pressure 94.9 dB(A)
Operating Pressure 100 psi (0.7 MPa, 7 bar)
Sound pressure 91.6 dB(A)
Sound power 101.9 dB(A)
Environmental conditions rating
Indoor/outdoor use
Altitude Up to 4000 m
Maximum relative humidity To 99% up to 130° F To 99% up to 54° C
Pollution degree 11
Installation category 2
* Minimum flow rate is dependent on material being sprayed and mixing capability. Test your material specific to flow rate.
