Models
313292J 9
Models
Use the following matrix to define the construction of the sprayer, based on the six digits. For example, Part XMEA00
represents an XM Plural-Component OEM sprayer (XM); 5200 psi pump set with pump filters (E); wall power supply
that is not approved for hazardous areas (A).
NOTE: To order replacement parts, see Parts section the XM Plural-Component Sprayer Repair-Parts manual
313289. The digits in the matrix do not correspond to the Ref. Nos. in the Parts drawings and lists.
NOTE: See Accessories and Kits, page 26, for a list of
available accessories and kits.
XM OEM sprayers are not approved for use in
hazardous locations.
XM E A
00
First and Second
Digits
Third Digit Fourth Digit
Fifth and Sixth
Digits
System Choice
(See Table 1 for lower models) Control Box Choice
Pump Set
(hose/gun) Pump Filters
Remote
Manifold Control Box Always 00
XM
(OEM plural
component sprayer
without a frame)
A no pumps A Wall Power Supply
B no pumps
✔
D Alternator
E 5200 psi
✔
F 5200 psi
G 6300 psi
✔
H 6300 psi
Code
System Pressure
(MPa, bar)
Pump
Filters
A Lower
(see manual 311762)
B Lower
(see manual 311762)
E 5200 psi (35, 350)
✔
L250C4 L220C4
F 5200 psi (35, 350) L250C3 L220C3
G 6300 psi (49, 490)
✔
L180C4 L145C4
H 6300 psi (49, 490) L180C3 L145C3
Table 1: : Lower Models and Corresponding Identification Codes
