Component Identification
313292J 11
Component Identification
Key:
A Pump Assembly
B Fluid Control Assembly (see Fluid Control Assembly,
page 12)
C Control Box
D User Interface Display (see User Interface Display, page
15)
E Air Controls (see Air Controls, page 13)
F Air Inlet Manifold Assembly
68 Air Line
69 Air Line
FIG. 1: Typical OEM Sprayer Components
WLD
A
B
C
F
E
D
68
69
