Graco XM Series Repair Parts

Parts
313289W 65
XM_ N _ _ Parts Varying by Top-Level Part Number
See Models, page 9, for components equipped on your system.
Model Part Description For additional information, refer to:
XM1N00 XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
XM1N10
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM1N20
XM1D00 SYSTEM, XM50, BF, IS
XM1_ _ _ Models, page 78
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM3N00 XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
XM3N10
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM3N20
XM3D00 SYSTEM, XM70, BF, IS
XM3_ _ _ Models, page 79
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM5N00 XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
XM5N0E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM5N0W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOSE, heated, wat, 240 V-H
Water-Jacketed Heated Hose, page 93
XM5N10
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM5N1E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM5N1W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, wat, 240 V-H
Water-Jacketed Heated Hose, page 93
XM5N20
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM5N2E
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM5N2W
XM5D00 SYSTEM, XM50, BF, R, IS
XM5_ _ _ Models, page 80
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
- - - HOSE, heated, wat, 240 V-H
Water-Jacketed Heated Hose, page 93
XM7N00 XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
XM7N0E
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM7N0W
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HOSE, heated, wat, 240 V-H
Water-Jacketed Heated Hose, page 93
XM7N10
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
XM7N1E
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM7N1W
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HOPPER, 10 gallon, ss
10-Gallon Hopper Parts, page 92
- - - HOSE, heated, wat, 240 V-H
Water-Jacketed Heated Hose, page 93
XM7N20 XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
XM7N2E
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
- - - HOSE, heated, electric, 240 V-H
Heated Hose manual
XM7N2W
XM7D00 SYSTEM, XM70, BF, R, IS
XM7_ _ _ Models, page 81
- - - HOPPER, 25 gallon, ss lined, 240 V
25-Gallon Hopper Parts, page 91
- - - HOSE, heated, wat, 240 V-H
Water-Jacketed Heated Hose, page 93
